Evolux Fiber: Koj tus kws tshaj lij Fiber Optic Terminal Box Chaw tsim khoom!

Shenzhen Evolux Fiber Co., Ltd yog ib tug thawj coj ntawm kev txiav -ntug kho qhov muag fiber ntau cov kev daws teeb meem, tshwj xeeb hauv kev tshawb fawb, kev tsim kho, kev tsim khoom, thiab kev faib khoom ntawm qib siab - fiber ntau optic khoom. Tsim nyob rau hauv 2013 xyoo, thiab headquartered nyob rau hauv Shen Zhen, Tuam Tshoj, peb tau tshwm sim raws li ib tug ntseeg lub npe nyob rau hauv lub teb ntawm fiber optics. Nrog rau kev tsom mus rau kev tsim kho tshiab thiab kev ntseeg siab, peb siv zog ua kom tau raws li qhov xav tau hloov zuj zus ntawm kev lag luam kev sib txuas lus thoob ntiaj teb.

null

Peb Qhov Zoo

Ntau yam khoom Portfolio

Peb muab ntau yam khoom siv kho qhov muag fiber ntau, los ntawm ib qho -hom thiab ntau- hom optical fibers mus rau cov khoom siv kho qhov muag tshwj xeeb rau cov kev siv tshwj xeeb, suav nrog cov fiber ntau optical cables, connectors, transceivers, adapters, thiab lwm yam khoom siv kom tau raws li cov kev xav tau ntawm peb cov neeg siv khoom.

Kev Pab Txhawb Cov Neeg Siv Khoom Zoo

Peb tau sib sau ua ke pab pawg kws tshaj lij uas tau npaj los txhawb peb cov neeg siv khoom. Lawv pab cov neeg siv khoom xaiv txoj kev daws teeb meem fiber ntau thiab coj cov txheej txheem kev siv, tso cai rau cov neeg siv khoom txaus siab rau kev ua ntej - kev sib tham txog kev muag khoom los tshaj tawm - kev muag khoom thiab kev pab cuam.

Advanced R & D Facilities

Xeev- ntawm-- cov chaw R&D kos duab, khoom siv, thiab cov chaw sim tshwj xeeb muab qhov chaw zoo tshaj plaws rau kev txiav- kev tshawb fawb, kev sim, thiab kev sim cov khoom siv fiber ntau, kev tsim, thiab kev tsim khoom.

Kev Customization Services

Peb muab cov kev xaiv customization uas tso cai rau cov neeg siv khoom los txiav cov khoom siv fiber ntau rau lawv cov kev xav tau tshwj xeeb. Fiber txoj kab uas hla, txheej khoom, los yog connector hom tuaj yeem hloov kho tau yooj yim.

Add to Inquiry

ABS Terminal Box 24 Core Nrog Splice Tais Phab Ntsa Mount lossis Ncej Mount

ABS terminal box 24 core nrog splice tais phab ntsa mount lossis ncej mount. ● Dej-pov thawj tsim nrog IP65 tiv thaiv qib. ●Integrated nrog splice cassette thiab cable tswj system. ● Tswj cov fibers

Add to Inquiry

16 Cores Optical Fiber Terminal Box Sab nraum zoov Mounted

Peb 16 Cores Optical Fiber Terminal Box Sab Nraud Phab Ntsa Mounted yog ib qho kev cog lus thiab siv tau zoo rau kev tswj xyuas fiber ntau, tshwj xeeb hauv FTTH tes hauj lwm. Feem ntau suav hais tias

Add to Inquiry

FTTH 2Core Fiber Optic Termination Box

FTTH 2Core Fiber Optic Termination Box. ● Xim: Dawb. ● Loj: 86 * 114 * 23mm. ● Yooj yim installation thiab txij nkawm. ● Dawb logo luam tawm. ●Load lossis unload pigtail, adapter. ● Cov qauv muaj

Add to Inquiry

8 Core Fiber Optic Distribution Box Cov ntaub ntawv pov thawj dej pov thawj

8 Core Fiber Distribution Box ABS Phab ntsa Mounted Fiber Optic Terminal Box rau sab nraum zoov siv. Dimension (L × W × H): 199 * 160 * 46mm. ● Khoom PC + ABS. ● ntub-pov thawj, dej-pov thawj, plua

Add to Inquiry

Pre-connectorized Fiber Distribution Box 8-12core

Pre-Connectorized Fiber Distribution Box 8-12cov tub ntxhais muaj kev tswj xyuas cov kab hluav taws xob zoo rau kev xa tawm network. Tsim los ntawm cov khoom siv PP ruaj khov, lub thawv muaj zog no

Add to Inquiry

9 Cores Waterproof Fiber Distribution Box

Fiber Termination Box (FTB), feem ntau hu ua Optical Termination Box (OTB), yog ib qho kev sib cog lus thiab muaj txiaj ntsig zoo rau kev tswj fiber ntau. 9 Cores Waterproof Fiber Distribution Box

Add to Inquiry

12 Cores Optical Fiber Terminal Box

12 Cores Optical Fiber Terminal Box. ● UV tsis kam. ● Ultrasonic vuam. ●Kev sealing zoo heev. ● Waterproof rau IP68

Add to Inquiry

Fiber Optic Terminal Box 2 Core

Qhia txog Fiber Optic Terminal Box 2 Core, kev cog lus, kev daws teeb meem zoo rau kev sib txuas ntawm fiber ntau. Ntsuas 86*86*21 hli, lub thawv davhlau ya nyob twg no yog tsim los kom haum rau 2

Add to Inquiry

Fiber Optic Terminal Box 4 Core

Peb Fiber Optic Terminal Box 4 Core yog cov kws tshaj lij rau FTTx daim ntawv thov, muab qhov chaw dav dav rau kev sib txuas, sib cais, khaws cia, thiab kev tswj fiber ntau. Nws lub teeb yuag thiab

Add to Inquiry

Fiber Optic Terminal Box 6 Core

Fiber Optic Terminal Box 6 Core. ● Khoom siv: PC + ABS. Qhov Loj: 186 * 116 * 41mm. ● Nruab rau hauv phab ntsa-mounted lossis ncej-mounted. ● ntub-pov thawj, dej-pov thawj, plua plav-pov thawj, tiv

Add to Inquiry

Fiber Optic Terminal Box 8 Core

Tshawb nrhiav lub zog ntawm FTTH nrog peb Fiber Optic Terminal Box 8 Core. FTTH, los yog Fiber rau Lub Tsev, yog ib qho kev siv tshuab dav hlau uas siv fiber ntau-optic cables xa cov ntaub ntawv

Add to Inquiry

Fiber Optic Ftth Box 12 Core

Fiber Optic Ftth Box 12 Core. ●Wet-proof, dej-pov thawj, plua plav-pov thawj, tiv thaiv qib mus txog IP65. ● Kev tsim kho-lub teeb yuag yas muaj zog. ●Resistance rau tshuaj thiab UV nres. ● Phab ntsa

First 12 Last1/2

Fiber Optic Terminal Box Chaw tsim tshuaj paus rau FTTH thiab FTTx Projects

EVOLUX muab fiber ntau optic davhlau ya nyob twg thawv rau FTTH, FTTx, telecom access networks, nyob broadband, lub tsev faib systems thiab cov neeg siv khoom - sab fiber ntau installation.

Peb cov khoom lag luam suav nrog cov thawv sab hauv thiab sab nraum zoov, phab ntsa-mounted thiab ncej-mounted enclosures, compact subscriber boxes, multi-core fiber distribution boxes thiab pre-connectorized solutions.

Ntxiv rau cov qauv qauv, peb txhawb nqa qhov project-kev teeb tsa tshwj xeeb, ua ntej- cov khoom sib dhos thiab OEM / ODM fiber optic davhlau ya nyob twg lub thawv cov kev pabcuam. Cov khoom tuaj yeem muab tau raws li qhov khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob khoob, los yog sib dhos nrog cov adapters, pigtails, splice trays, PLC splitters, thiab mounting accessories raws li koj qhov project xav tau.

Txawm hais tias koj yog tus tswv lag luam hauv xov tooj, FTTH tus neeg cog lus, tus neeg sib koom ua ke network, distributor lossis tus kheej -label hom, peb pab neeg tuaj yeem pab koj xaiv lossis tsim cov kev daws teeb meem fiber ntau uas haum rau koj qhov chaw teeb tsa, cov qauv hauv network thiab pob nyiaj siv.

Yuav Ua Li Cas Fiber Optic Terminal Boxes Raug Tsim?

Ib qho kev txhim khu kev qha fiber ntau optic davhlau ya nyob twg yuav tsum muaj kev sib koom ua ke thiab cov qauv sab hauv.

Cov khoom siv hauv tsev, cable nkag tsim, sealing system, splice tray, adapter vaj huam sib luag, fiber ntau routing qhov chaw thiab mounting qauv yuav tsum ua hauj lwm ua ke los txhawb kev txhim kho kom zoo thiab ntev - lub sijhawm ua haujlwm network.

Txoj kev tsim khoom yog nyob ntawm cov khoom ntim khoom xaiv thiab cov qauv khoom.

Yas Fiber Optic Terminal Box Manufacturing

Plastic Terminal Boxes feem ntau koom nrog cov theem hauv qab no:

Product Structure Review

Lub qhov ntev ntawm lub qhov rooj, qhov chaw nkag cable, splice tais, adapter vaj huam sib luag, mounting qauv thiab sealing txoj kev raug tshuaj xyuas ua ntej ntau lawm.

Xaiv cov khoom siv

Cov ntaub thaiv npog raug xaiv raws li cov khoom tsim, ib puag ncig kev teeb tsa, kev xav tau ntawm cov khoom siv thiab huab cua - cov kev cai tiv thaiv.

Cov khoom xaiv muaj nyob ntawm tus qauv lub thawv davhlau ya nyob twg thiab tej zaum yuav suav nrog ABS, PC, PC + ABS, PP lossis lwm yam khoom siv ntsuas.

Txhaj Molding

Lub npog npog, hauv paus, splice tais thiab lwm yam molded qhov chaw yog tsim los siv cov cuab yeej paub tseeb thiab cov khoom siv.

Trimming thiab tshwm sim tshuaj xyuas

Moulded qhov chaw raug kuaj xyuas qhov burrs, deformation, tawg, molding tsis tiav, deg tsis xws luag thiab qhov sib xws.

Kev npaj sab hauv

Splice trays, adapter panels, cable clamps, sealing Cheebtsam, locks, fasteners thiab mounting accessories yog npaj raws li qhov tseeb BOM.

Cov khoom sib dhos

Cov ntaub thaiv npog, cov tais sib txuas, cov ntsaws ruaj ruaj, xauv, cable- cov khoom nkag thiab cov khoom siv sab hauv tau sib sau ua ke.

Optional Component Loading

Adapters, pigtails, PLC splitters thiab lub tes tsho tiv thaiv tuaj yeem ntsia tau raws li cov khoom tsim nyog.

Kev tshuaj xyuas thiab ntim

Cov thawv tiav tiav raug tshuaj xyuas tawm tsam cov khoom lag luam pom zoo ua ntej ntim.

Dab tsi yog Fiber Optic Terminal Box?

Lub thawv kho qhov muag fiber ntau yog lub thawv uas tiv thaiv fiber ntau optic cable thiab fiber ntau pigtail vuam ntawm lub davhlau ya nyob twg ntawm fiber ntau optic cable. Nws yog tsuas yog siv rau qhov ncaj- los ntawm vuam thiab ceg splicing ntawm sab hauv thiab sab nraum zoov fiber ntau optic cables thiab kho cov fiber optic cable davhlau ya nyob twg, uas plays lub luag hauj lwm ntawm fiber pigtail cia thiab tiv thaiv kev sib koom tes. Nws tuaj yeem faib cov khoom siv kho qhov muag rau hauv ib qho fiber ntau kho qhov muag, uas yog sib npaug rau cov khoom sib txuas, uas ua lub luag haujlwm ntawm kev sib txuas ntawm cov khoom siv kho qhov muag thiab cov pigtail. Tom qab ib qho khoom siv kho qhov muag tuaj txog ntawm tus neeg siv kawg, nws tau tsau rau hauv lub thawv davhlau ya nyob twg, thiab cov tub ntxhais thiab pigtail hauv qhov kho qhov muag cable yog welded rau hauv lub thawv davhlau ya nyob twg.

Hom Fiber Optic Terminal Boxes

Phab ntsa-mounted thiab khib-mounted
Fiber Termination Boxes tuaj yeem muab faib ua khib-mounted thiab phab ntsa-mounted thawv raws li lawv tsim. Lub tom kawg yog feem ntau kaw thiab dai rau ntawm phab ntsa, thaum yav tas los muaj lub rear thiab pem hauv ntej qhov rooj nrog ib sab rail txuas ncaj qha mus rau lub khib ntawm lub server. Phab ntsa-mounted FTB feem ntau txhais tau tias rau kev sib txuas ncaj qha. Cov txheej txheem xws li fusion, splicing, thiab txiav yuav tsum tau ua ua ntej lub installation ntawm FTB. Lub phab ntsa-mounted fiber ntau lub thawv tau zoo- haum rau cov ntawv thov xws li kev sib tham hauv xov tooj, lub tsev nkag nkag, thiab lwm yam. Cov FTBs no tuaj yeem muab faib ntxiv rau hauv cov thawv sab nraum zoov thiab sab hauv tsev. Ntawm qhov tod tes, khib-mounted enclosures yog qhov zoo tagnrho rau kev sib txuas lossis hla- txuas architecture. Xws li FTBs yog qhov zoo tagnrho rau kev tsim kev sib txuas ntawm cov khoom siv sib kis thiab cov nroj tsuag sab nraud, nrog rau qhov chaw txaus rau kev tswj hwm, txiav tawm, faib, thiab fusion. Rack{15}}mounted FTBs, txawm li cas los xij, tsuas yog rau kev xa tawm sab hauv tsev.

Sab hauv thiab sab nraum zoov
Raws li lawv cov ntawv thov hauv ntau qhov chaw, FTBs tuaj yeem muab faib ua pawg ntawm cov thawv txiav tawm sab nraud thiab sab hauv tsev. Qhov sib txawv tseem ceeb ntawm lawv yuav yog cov khoom siv rau kev tsim khoom. Cov ntaub ntawv siv nyob rau hauv ib chav tsev yuav tsum muab piv rau cov siv nyob rau hauv lwm yam, thiab txawm lub cable / pigtail sheaths. Nyob rau hauv rooj plaub uas tus FTB txhais tau tias rau kev xa tawm sab nraum zoov, nws cov khoom siv tshuaj thiab lub cev yuav tsum ruaj khov txaus nrog kev ua haujlwm zoo rau dej thiab plua plav. Lub melting kub ntawm cov ntaub ntawv kuj yuav tsum tsis txhob tsawg tshaj li 120 degree. FTB Cheebtsam yuav tsum ua haujlwm dhau qhov ntsuas kub ntau yam tsawg kawg yog -25℃txog 45℃kom muaj sia nyob qhov kub hloov pauv loj. Nws cov casing sab nrauv yog feem ntau zoo kaw los tiv thaiv cov khoom sab hauv los ntawm kev puas tsuaj thiab muaj kev cuam tshuam siab. Sab hauv FTB, ntawm qhov tod tes, paub tias yog qhov hloov pauv ntawm kab rov tav thiab sab saud. Lawv feem ntau yog siv los ua qhov chaw cia rau kev faib khoom fiber ntau thiab txiav tawm hauv ntau qhov chaw tswj hwm thiab yog li tsis muaj qhov tshwj xeeb ntawm cov khoom siv. Txhawm rau xaiv qhov zoo tshaj plaws fiber ntau lub thawv rau koj lub network, koj yuav tsum ntsuas koj cov kev xav tau muaj peev xwm thiab xaiv qhov kev xaiv uas zoo sib xws nrog koj cov kev xav tau. FTBs tuaj yeem pom nyob rau hauv ntau yam ntaub ntawv, duab, thiab ntau thiab tsawg. Koj yuav tsum tau coj mus rau hauv tus lej ntawm cov fibers siv thiab qhov chaw muaj, ntawm lwm yam, txhawm rau txheeb xyuas qhov uas yuav ua haujlwm zoo tshaj plaws rau koj lub rooj sib txoos.

Muaj nuj nqi ntawm Fiber Optic Terminal Box

Qhov kev ua haujlwm ntawm lub thawv optical fiber ntau yog muab cov fusion splicing ntawm optical fiber ntau thiab optical fiber, fusion splicing ntawm optical fiber ntau thiab pigtail, thiab kev xa mus ntawm optical connector. Nws kuj tseem muab kev tiv thaiv kev tiv thaiv ib puag ncig thiab kev tiv thaiv ib puag ncig rau cov khoom siv kho qhov muag fiber ntau thiab nws cov khoom, thiab tso cai rau kev tshuaj xyuas kom zoo los tuav cov qauv siab tshaj plaws ntawm kev tswj xyuas fiber ntau. Lub thawv zoo fiber ntau optic yuav tsum muaj cov haujlwm hauv qab no.
Kho Function
Tom qab cov khoom siv kho qhov muag nkag mus rau hauv lub khib, nws cov ntaub qhwv sab nrauv thiab cov tub ntxhais tseem ceeb yuav tsum tau kho kom zoo, cov khoom siv hauv av yuav tsum tau muab tso rau, kev tiv thaiv kawg, thiab kho qhov muag fiber ntau thiab kev tiv thaiv.
Splicing Function
Tom qab cov khoom siv kho qhov muag tau kos los ntawm cov kab hluav taws xob kho qhov muag yog spliced nrog tus Tsov tus tw cable, cov khoom siv fiber ntau yog coiled thiab khaws cia, thiab kev sib txuas sib txuas yog tiv thaiv.
Kev faib ua haujlwm
ntsaws lub connector txuas rau tus Tsov tus tw cable rau lub adapter, thiab paub qhov kev sib txuas kho qhov muag nrog lub qhov muag txuas ntawm lwm sab ntawm lub adapter. Adapters thiab connectors yuav tsum muaj peev xwm muab tau yooj yim ntxig thiab tshem tawm; txoj kev kho qhov muag tuaj yeem siv dawb thiab sim.
Storage Function
Muab qhov chaw khaws cia ntawm ntau yam ntoo khaub lig- txuas kho qhov muag cables ntawm racks, kom lawv tuaj yeem muab tso rau hauv ib txwm thiab ua kom zoo. Yuav tsum muaj qhov chaw tsim nyog thiab txoj hauv kev hauv lub thawv kho qhov muag fiber ntau los ua kom cov xaim ntawm qhov no ntawm cov kab sib txuas kho qhov muag pom tseeb, kho tau yooj yim, thiab ua tau raws li qhov tsawg kawg nkaus khoov vojvoog.

Daim ntawv thov ntawm Fiber Optic Terminal Box

Fiber Optic Distribution

Terminal thawv yog siv los faib thiab teeb tsa cov fiber ntau optic cables hauv ib lub tsev lossis ib cheeb tsam. Lawv muab cov qauv tsim thiab nkag tau yooj yim rau kev txuas ntau yam fiber ntau optic cables.

Sab hauv Fiber Optic Termination

Nyob rau hauv ib puag ncig sab hauv xws li cov chaw zov me nyuam, chaw ua haujlwm, lossis cov tsev nyob, Fiber Optic Terminal Boxes yog siv los txiav thiab teeb tsa cov fiber ntau optic cables. Lawv feem ntau tuaj nrog ua ntej - teeb tsa adapters kom yooj yim ntsaws- thiab - ua si txuas.

Fiber rau Tsev (FTTH) Installations

Hauv FTTH xa tawm, Fiber Optic Terminal Boxes yog siv los txiav cov fiber ntau optic cables ntawm tus neeg siv khoom qhov chaw. Cov thawv no tuaj yeem siv lub tsev txuas lossis cov khoom siv txuas rau cov neeg siv khoom, xws li routers lossis optical network terminals (ONTs).

Cov ntsiab lus sib txuas rau cov neeg siv khoom

Terminal thawv ua haujlwm raws li cov neeg siv khoom sib txuas cov ntsiab lus, muab qhov chaw rau splicing, txuas, thiab tswj fiber optic cables rau ib tus neeg siv lossis cov neeg siv khoom hauv lub network.

Fiber Termination Box Installation txheej txheem

Mounting

Optical fiber termination box yog mounted rau ntawm phab ntsa los yog ntawm 19 ntiv tes (483 mm) dav txheem khib. Lub vaj huam sib luag pem hauv ntej yuav tsum tau yooj yim nkag tau raws li cov cable nkag los hauv qab.

Cable End Kev Npaj

Txhua qhov fiber ntau cable kawg yuav tsum tau npaj ua ntej pib lub cable nkag rau hauv lub thawv kho qhov muag fiber ntau. Cov txheej txheem kev npaj cable kawg yog muaj los ntawm tus neeg muag khoom. Nws yog ib qho tseem ceeb los tiv thaiv cov liab qab fibers nyob rau theem no. Qhov no yog vim lawv tau nthuav tawm tom qab ua raws li qhov kev npaj ntawm cable kawg.

Cable nkag

Thaum lub cable xaus tau npaj, ib tug roj hmab diaphragm ntawm lub thawv lub cable nkag qhov yuav tsum tau pierced. Qhov no yuav tsum tau ua ua ntej tso lub cable rau hauv lub thawv, vim tias qhov qhib no tau thaiv hauv cov thawv tshiab.

Cable End Clamping

Lub thawv txiav fiber ntau muaj ntau lub hnab yas fiber ntau cov ntawv qhia mounted rau hauv nws. Lub fiber nyob rau hauv lub tes tsho los yog thauj tube ntawm lub cable yog routed los ntawm lawv. Los ntawm cov ntawv qhia no, tag nrho qhov ntev ntawm lub cable raug coj mus rau hauv lub tais xaiv splice. Tom qab ntawd, siv cov yas clamping pluaj, nws yog clamped ntawm lub splice tais qhov chaw nkag.

Splicing

Qhov tseem ceeb tshaj plaws ntawm cov txheej txheem installation yog splicing lub optical fiber los ntawm lub cable mus rau pigtails. Lub tshuab splicing yog siv rau lub hom phiaj no. Nws yog khaws cia ze rau lub thawv txiav tawm ntawm lub rooj. Lub tshuab hlau stainless hlau yog tso tawm los ntawm nws lub caij nplooj ntoos hlav ntes kom qhib ib lub tais tshwj xeeb. Lub tshuab splicing yog siv los splice lub pigtail fibers kom cov fibers xaus tawm ntawm lub cable. Tom qab ntawd lawv raug thawb kom haum rau hauv fused splice. Cov txheej txheem yog nqa mus rau tag nrho cov splices yuav tsum tau muab cia rau hauv splice tais. Cov tais splice no tau muab tso rau hauv ib pawg hauv lub thawv txiav. Lub stainless hlau xaim kaw mechanism yog ces kaw nrog lub thawv.

Yam yuav tsum tau xav txog ua ntej xaiv Fiber Optic Terminal Box

Muaj peev xwm
Lub peev xwm ntawm fiber ntau optic davhlau ya nyob twg lub thawv yog ib qho tseem ceeb tshaj plaws los xav txog. Nws txiav txim siab tus naj npawb ntawm fiber ntau optic cables uas tuaj yeem nyob hauv lub thawv. Lub peev xwm ntawm lub thawv yuav tsum yog raws li koj qhov kev xav tau tam sim no thiab kev loj hlob yav tom ntej. Nco ntsoov xaiv lub thawv uas muaj peev xwm txaus kom haum rau yav tom ntej nthuav dav ntawm koj lub network.
Loj
Qhov loj ntawm fiber ntau optic davhlau ya nyob twg lub thawv kuj yog ib qho tseem ceeb uas yuav tau xav txog. Lub thawv yuav tsum loj txaus kom haum rau tag nrho cov fiber optic cables thiab lwm yam khoom siv ntxiv uas yuav xav tau. Txawm li cas los xij, nws yuav tsum tsis txhob loj heev uas nws siv ntau qhov chaw lossis nyuaj rau kev teeb tsa.
Kev tiv thaiv
Fiber optic davhlau ya nyob twg lub thawv yuav tsum muaj kev tiv thaiv txaus rau cov fiber ntau optic cables los ntawm lub cev puas tsuaj, plua plav, thiab ya raws. Xaiv ib lub thawv uas yog ua los ntawm cov khoom zoo - thiab muaj kev ruaj ntsegxauv mechanism los tiv thaiv kev nkag tsis tau. Lub thawv yuav tsum muaj cov ntsaws ruaj ruaj thiab gaskets kom tsis txhob ya raws thiab plua plav nkag.
Kev sib txuas
Fiber optic davhlau ya nyob twg lub thawv yuav tsum tau sib xws nrog hom fiber ntau optic connectors uas koj siv. Cov khoom sib txawv xws li SC, LC, thiab ST. Nco ntsoov xaiv lub thawv uas tuaj yeem ua raws li hom kev sib txuas uas koj siv.
Yooj yim ntawm installation
Fiber optic davhlau ya nyob twg lub thawv yuav tsum yooj yim rau nruab thiab siv. Nrhiav ib lub thawv uas los nrog cov lus qhia meej thiab tag nrho cov khoom tsim nyog mounting. Lub thawv yuav tsum yooj yim rau kev nkag mus thiab khaws cia.
Nqe
Nqe ib txwm yog qhov tseem ceeb thaum xaiv cov khoom lag luam. Tus nqi ntawm fiber ntau optic davhlau ya nyob twg lub thawv yuav tsum muab piv nrog nws cov yam ntxwv thiab kev ua haujlwm. Xaiv lub thawv uas muaj txiaj ntsig zoo rau cov nyiaj thiab nyob hauv koj cov peev nyiaj.

Qhov kawg FAQ Qhia rau Fiber Optic Terminal Box

Q: Dab tsi yog fiber optic davhlau ya nyob twg lub thawv?

A: Lub thawv optical fiber ntau lub thawv yog lub thawv uas tiv thaiv fiber ntau optic cable thiab fiber ntau pigtail vuam ntawm lub davhlau ya nyob twg ntawm fiber ntau optic cable.

Q: Lub npe ntawm lub thawv fiber ntau yog dab tsi?

A: Lub thawv fiber ntau (FTB), lub npe hu ua optical termination box (OTB) ib yam nkaus, yog cov khoom siv tswj fiber ntau ntawm me me. Nws yog dav siv nyob rau hauv FTTx cabling rau ob qho tib si fiber ntau cabling thiab cable tswj.

Q: Yuav ua li cas rau nruab lub fiber optic davhlau ya nyob twg lub thawv?

A: Fiber optic hlws ris thawv yuav tsum tau muab ntsia kom ze rau thaj chaw ua haujlwm kom tsis txhob muaj qhov ntev ntawm cable. Koj tuaj yeem siv optical spltters thiab fiber ntau optics nrog luv luv cables rau kev sib txuas hauv network yog tias xav tau ntev dua. Koj yuav tsum tau nruab lub fiber optic enclosure raws li cov chaw tsim khoom cov lus qhia. Xav txog tej yam xws li teeb pom kev zoo, kev tswj qhov kub thiab txias, kev ruaj ntseg, thiab kev sib txuas ntawm lub davhlau ya nyob twg yuav zoo tshaj. Koj tuaj yeem ntiav cov kws tshaj lij kev teeb tsa los pab txhim kho lossis tswj cov thawv fiber ntau optic. Lub thawv optical filber davhlau ya nyob twg yog qhov tseem ceeb ntawm FTTH network. Cov cuab yeej no yog lub luag haujlwm rau kev sib kis thiab xa tawm ntawm cov teeb liab kho qhov muag. Txhawm rau kom muaj kev ua haujlwm zoo ntawm lub thawv davhlau ya nyob twg, nws yuav tsum tau tsim kom tsim nyog thiab khaws cia tsis tu ncua. Qhov no yuav pab kom tsis txhob muaj kev puas tsuaj lossis poob ntawm lub teeb liab.

Q: Dab tsi yog fiber ntau termination box?

A: Hauv kev sib txuas hauv network, kev sib txuas sab nraum zoov feem ntau siv fiber ntau optic cables. Thaum cov fibers kho qhov muag tau teeb tsa lossis tso tawm, Fiber Termination Box, lossis FTB, yog siv los faib thiab tiv thaiv cov kev sib txuas ntawm fiber ntau hauv FTTH tes hauj lwm. Fiber termination box yog ib qho kev sib txuas ntawm fiber ntau cable los ntawm cov kab sab thiab cov pigtails kom xa mus rau fiber ntau thav duab. Fiber pigtail yog ib qho kev sib txuas ntawm cov khoom siv tshwj xeeb siv rau kev txiav cable. Yog li, lub thawv fiber ntau yog siv los txiav cov fiber ntau optical cables nyob rau hauv lub tshav pob thiab txuas lawv mus rau pigtail los ntawm splicing. Tom qab ib qho optical cable tuaj txog ntawm tus neeg siv kawg, nws yog tsau rau hauv lub thawv davhlau ya nyob twg. Tom qab ntawd, cov tub ntxhais optical cable thiab pigtail yog welded rau hauv lub thawv davhlau ya nyob twg. Cov thawv no zoo ib yam li MDF hauv kev sib pauv xov tooj. Muaj cov cassettes muab rau hauv lub thawv no uas ua kom cov fibers muaj kev nyab xeeb tom qab fusion splicing. Ib qho ntxiv fiber ntau los ntawm kab sab lossis pigtails tuaj yeem khaws cia rau hauv lub thawv txiav. Nws kuj ua raws li qhov taw tes rau kev sib tw thiab rov ua cov kab hluav taws xob kho qhov muag.

Q: Yuav ua li cas rau nruab thiab siv Fiber Optic Terminal Box?

A: Fiber optic davhlau ya nyob twg thawv feem ntau yog siv sab hauv tsev. Yog tias lawv siv sab nraum zoov, kev tiv thaiv tsim nyog yuav tsum tau coj los tiv thaiv cua thiab nag los ntawm kev ua haujlwm luv luv ntawm lub thawv davhlau ya nyob twg.

Fiber optic davhlau ya nyob twg lub thawv yog tsim rau kev khiav hauj lwm ntawm qhov kub ntawm -25℃mus rau 40 degree, tshaj qhov kev ua haujlwm ntawm lub thawv fiber ntau yuav raug cuam tshuam.

Lub neej ua haujlwm ntawm txhua qhov system thiab kev ntsuas feem ntau yog kwv yees li 20 xyoo. Txhawm rau kom ntseeg tau tias lub neej ua haujlwm, ib puag ncig rau khaws cia lub thawv fiber ntau muaj qee qhov kev xav tau ntawm qhov kub, av noo thiab huab cua siab. Piv txwv li, nws yog qhov zoo tshaj kom khaws cia kub ntawm -25℃thiab 55 degree, huab cua siab ntawm 70 thiab 107 kPa, thiab cov av noo qis dua 85 feem pua.

Q: Dab tsi yuav tsum tau pom hauv lub thawv fiber ntau optical?

A: Them mloog mus rau lub installation txoj hauj lwm ntawm lub fiber optic davhlau ya nyob twg lub thawv thiab xaiv ib tug tsim nyog installation txoj kev. Feem ntau hais lus, qhov chaw teeb tsa ntawm lub thawv fiber ntau optic davhlau ya nyob twg yuav tsum yog 0.3 meters saum toj no hauv av kom tso chaw txaus rau kev txhim kho cov khoom xws li hauv qab rooj plaub, SS fiber ntau optical adapter, thiab lub qhov hluav taws xob sab nraud.

Thaum tuav lub thawv fiber ntau optic davhlau ya nyob twg, koj tuaj yeem siv cov cuab yeej sib txawv thiab txoj hauv kev, xws li nthuav cov ntsia hlau thiab tua cov ntsia hlau raws li qhov chaw nyob. Yog tias cov cuab yeej yuav tsum tau muab tso rau hauv av, yuav tsum tau them nyiaj mloog rau cov dej tsis zoo thiab plua plav ua haujlwm ntawm lub thawv sib txuas, thiab ntxiv dag zog rau nws txoj kev tiv thaiv - siab thiab tiv thaiv - muaj peev xwm seismic.

Nov yog lub ntiaj teb ntawm cov ntaub ntawv, thiab txhua tus neeg nyob hauv cov ntaub ntawv loj. Fiber optic davhlau ya nyob twg lub thawv yog ib qho tseem ceeb ntawm cov neeg nqa khoom nyob rau hauv cov txheej txheem ntawm cov ntaub ntawv xa mus thiab yog obviously lub ntsiab ntawm cov ntaub ntawv kev sib txuas lus thiab cov ntaub ntawv kis kev lag luam nyob rau hauv lub tam sim no era. Fiber optic davhlau ya nyob twg lub thawv yog dav siv nyob rau hauv ntau lub teb, xws li fax, xov tooj hauv zos, thiab network, nws muaj nuj nqis thiab cov tswv yim siv tau pom.

Q: Lub luag haujlwm ntawm fiber ntau optic davhlau ya nyob twg thawv hauv FTTH tes hauj lwm yog dab tsi?

A: Fiber optic davhlau ya nyob twg thawv yog siv los muab cov ntsiab lus fiber optic txiav nrog cov chaw kuaj ntawm cov xaim xaim thiab cov xaim sab hauv ntawm cov neeg siv khoom. Lub thawv fiber optic davhlau ya nyob twg yuav tsum tau muab ntsia rau ntawm phab ntsa sab nrauv ntawm cov neeg siv khoom lub tsev lossis hauv chav sib txuas lus xaiv. Optical fiber terminal boxes feem ntau ntsia rau ntawm phab ntsa ntawm cov neeg siv khoom lub tsev los pab cov neeg siv khoom los muab cov kev pabcuam FTTH. Fiber optic davhlau ya nyob twg thawv yuav tsum tau sib xws nrog telecom tswv 'installation qauv thiab kev khiav hauj lwm thiab txij nkawm specifications. Fiber optic davhlau ya nyob twg thawv yuav tsum haum rau sab nraud ib puag ncig thiab tsim rau sab nraum zoov installation, haum rau flush mount, nto mount rau pob zeb phab ntsa los yog ncej mount. Kev teeb tsa lub thawv fiber ntau optic yuav tsum tau siv cov cuab yeej siv tes yooj yim xwb.

Q: Tus qauv ntawm Fiber Optic Terminal Box yog dab tsi?

A: Lub thawv optical cable davhlau ya nyob twg yog tsim los ntawm peb qhov chaw: lub plhaub, ib qho khoom siv sab hauv, thiab cov khoom siv kho qhov muag fiber ntau.

Plhaub

Lub plhaub yuav tsum yooj yim qhib thiab yooj yim rau nruab. Lub plhaub yuav tsum muaj cov hlau lead- tawm cov khoom siv rau qhov siab -voltage tiv thaiv hauv av ntawm cov khoom hlau ntawm cov khoom siv kho qhov muag.

Sab hauv Cheebtsam

Internal Cheebtsam yuav tsum muaj xws li cov hauv qab no:

Kev them nyiaj yug thav duab: lub cev tseem ceeb ntawm cov qauv sab hauv, siv rau kev txhawb nqa ntawm cov qauv sab hauv.

Fiber ntau lub tais: siv los khaws cov khoom siv kho qhov muag fiber ntau (thiab lawv qhov chaw tiv thaiv) thiab cov fibers seem nyob rau hauv ib qho kev txiav txim. Qhov ntev ntawm cov fibers seem yuav tsum tsis pub tsawg tshaj 1.6m, thiab lub vojvoog ntawm curvature ntawm cov seem fibers yuav tsum tsis txhob tsawg tshaj li 37.5 hli. Nws kuj tseem muab tau yooj yim -rau- txheeb xyuas cov lej fiber ntau thiab qhov chaw ua haujlwm yooj yim rau kev sib txuas.

Kho cov cuab yeej: siv los kho qhov kho qhov muag cable sheath, kho qhov kho qhov muag cable ntxiv dag zog rau cov tswv cuab, thiab kho cov hlua pigtail.

Q: Optical Fiber Connector Tiv Thaiv

A: Cov khoom siv fiber ntau tuaj yeem tiv thaiv los ntawm lub tshav kub -shrinkable tiv thaiv raj, tiv thaiv clip, thiab lwm yam.

Q: Dab tsi yog cov khoom siv ntawm Fiber Optic Terminal Box?

A: Cov khoom siv rau qhov chaw uas lub thawv optical cable davhlau ya nyob twg nyob yuav tsum muaj cov khoom tiv thaiv-corrosion. Yog tias tsis muaj kev tiv thaiv- kev ua haujlwm corrosion, nws yuav tsum tau kho nrog kev tiv thaiv -corrosion. Nws cov khoom siv lub cev thiab tshuaj lom neeg yuav tsum ruaj khov, thiab ntau yam ntaub ntawv yuav tsum sib haum nrog ib leeg thiab sib haum nrog lub cable sheath thiab xaim pigtail sheath. Txhawm rau tiv thaiv corrosion thiab lwm yam kev puas tsuaj hluav taws xob, cov ntaub ntawv no kuj yuav tsum tau sib xws nrog cov ntaub ntawv uas feem ntau siv hauv lwm yam khoom siv.

Q: Dab tsi yog qhov kev ua haujlwm kho qhov muag ntawm Fiber Optic Terminal Box?

A: Cov khoom siv kho qhov muag tseem tshuav nyob rau hauv lub thawv kho qhov muag cable yog coiled nyob rau hauv lub tais splice. Tom qab kev teeb tsa ntawm lub thawv kho qhov muag cable davhlau ya nyob twg, cov khoom siv kho qhov muag thiab cov khoom siv kho qhov muag yuav tsum tsis muaj kev cuam tshuam ntxiv.

Q: Dab tsi yog qhov txawv ntawm Fiber Terminal Box thiab Fiber Splice Tray?

A: Qee zaum, vim muaj cov qauv sab hauv zoo sib xws, tib neeg tuaj yeem sib xyaw fiber ntau optic davhlau ya nyob twg thawv nrog fiber ntau splice tais. Fiber optic davhlau ya nyob twg thawv feem ntau yog siv los ua lub davhlau ya nyob twg connectors rau splicing ib tug cable rau ntau fiber optic cables uas muaj connectors ntawm ib kawg thiab tsis muaj connectors ntawm lwm kawg. Qee lub sij hawm, fiber ntau splice tais nyob rau hauv lub fiber optic davhlau ya nyob twg lub thawv kom haum rau fused fiber ntau. Txawm li cas los xij, nws kuj tseem siv tau ib leeg los tiv thaiv cov welded fibers. Yog li ntawd, ob lub cuab yeej tsis hloov pauv tau.

Q: Dab tsi yog cov txiaj ntsig ntawm kev siv lub thawv fiber ntau optic?

A: Fiber optic davhlau ya nyob twg thawv ua lub luag haujlwm tseem ceeb hauv kev faib khoom thiab kev tswj hwm ntawm fiber ntau optic cables. Lawv tau tsim los muab txoj hauv kev ruaj ntseg thiab txhim khu kev qha los txuas thiab khaws cov fiber ntau optic cables.

Q: Dab tsi yog cov khoom ntawm fiber ntau optic davhlau ya nyob twg?

A: Fiber optic davhlau ya nyob twg lub thawv suav nrog lub plhaub sab nraud, cov khoom siv sab hauv (them txhawb nqa, lub tais ruaj khov, clamp), thiab fiber ntau optic connector tiv thaiv cov khoom.

Q: Vim li cas thiaj siv Fiber Termination Boxes?

A: FTBs muab qhov chaw ruaj ntseg thiab teeb tsa kev txiav tawm rau cov fiber ntau optic cables, ua kom yooj yim txij nkawm, scalability, thiab muaj txiaj ntsig kev faib tawm.

Q: Yuav ua li cas fiber splicing tuav hauv FTB?

A: Qee qhov FTBs suav nrog cov tais sib txuas rau fusion splicing, tso cai rau kev sib txuas ntawm ib tus neeg fibers rau seamless teeb liab kis tau tus mob.

Q: Lub FTB puas tuaj yeem yog phab ntsa-mounted?

A: Ntau FTBs yog tsim los rau phab ntsa-mounting, muab qhov chaw-txuag kev daws teeb meem rau me me installation.

Raws li ib qho ntawm cov ua fiber ntau optic davhlau ya nyob twg lub thawv manufacturers thiab lwm tus neeg nyob hauv Suav teb, peb sov siab txais tos koj mus yuav cov fiber ntau optic davhlau ya nyob twg lub thawv hauv Tshuag ntawm no los ntawm peb lub hoobkas. Tag nrho cov khoom customized yog nrog cov khoom zoo thiab tus nqi qis. Rau pricelist thiab dawb qauv, hu rau peb tam sim no.
