Nyob rau hauv niaj hnub no evolving sai heev cov toj roob hauv pes, txhim khu kev qha, high-ceev kev sib txuas yog qhov tseem ceeb rau kev lag luam kom ua tiav. Peb1X64 PLC Fiber Optic Splitteryog tsim tshwj xeeb los daws cov kev xav tau hloov pauv ntawm kev lag luam kev sib txuas lus thoob ntiaj teb. Siv cov cuab yeej siv hluav taws xob hluav taws xob, lub tshuab hluav taws xob no zoo tagnrho rau FTTX, EPON, BPON, thiab GPON daim ntawv thov. Nrog nws cov kev ua tau zoo ib yam, tsis tshua muaj qhov muag pom qhov poob, thiab kev ntseeg siab, peb lub splitter txhim kho kev saib xyuas thiab kev tswj hwm ntawm fiber ntau optic tes hauj lwm zoo.
Vim li cas thiaj xaiv US?
Ntawm Shenzhen Evolux Fiber Co., Ltd, peb muab qhov tseem ceeb ntawm kev tsim kho tshiab, kev ntseeg siab, thiab cov neeg siv khoom txaus siab. Peb txoj kev mob siab rau kev tshawb fawb thiab kev tsim kho kom ntseeg tau tias peb cov khoom ua tau raws li cov qauv zoo tshaj plaws thiab kev ua haujlwm zoo. Rov qab los ntawm pab pawg kws tshaj lij, peb muab kev pabcuam zoo tshaj plaws thiab kev pabcuam tomqab muag, ua rau peb muaj kev ntseeg siab hauv kev lag luam fiber ntau. Peb mob siab rau tsis yog tsuas yog ua tau raws li koj cov kev xav tau tab sis kuj tshaj li qhov koj xav tau. Nrog rau peb cov kev daws teeb meem, peb tsom kom xa cov kev paub tsis sib xws, muab cov khoom lag luam txhim khu kev qha thiab txiav-ntev los pab koj ua tiav hauv kev lag luam sai sai.
Khoom Specifications
|
Yam khoom |
1*2 |
1*4 |
1*8 |
1*16 |
1*32 |
1*64 |
1*128 |
|
Hom Fiber |
G.657A |
||||||
|
Ua haujlwm Wavelength |
1260nm ~ 1650nm |
||||||
|
Insertion Loss |
Tsawg dua lossis sib npaug rau 4.2 |
Tsawg dua lossis sib npaug li 7.6 |
Tsawg dua lossis sib npaug rau 10.7 |
Tsawg dua los yog sib npaug rau 14.0 |
Tsawg dua lossis sib npaug rau 17.2 |
Tsawg dua lossis sib npaug li 20.8 |
Tsawg dua lossis sib npaug rau 24.0 |
|
P-qib Insertion poob |
Tsawg dua los yog sib npaug rau 4.0 |
Tsawg dua lossis sib npaug rau 7.4 |
Tsawg dua lossis sib npaug li 10.5 |
Tsawg dua los yog sib npaug rau 13.8 |
Tsawg dua lossis sib npaug rau 17.0 |
Tsawg dua lossis sib npaug rau 20.4 |
Tsawg dua lossis sib npaug li 23.7 |
|
Kev tsis sib xws |
Tsawg dua lossis sib npaug rau 0.6 |
Tsawg dua lossis sib npaug rau 0.8 |
Tsawg dua lossis sib npaug rau 0.8 |
Tsawg dua los yog sib npaug rau 1.0 |
Tsawg dua los yog sib npaug li 1.5 |
Tsawg dua lossis sib npaug rau 2.0 |
Tsawg dua lossis sib npaug rau 2.0 |
|
PDL |
Tsawg dua lossis sib npaug rau 0.2 |
Tsawg dua lossis sib npaug rau 0.2 |
Tsawg dua lossis sib npaug rau 0.3 |
Tsawg dua lossis sib npaug rau 0.3 |
Tsawg dua lossis sib npaug rau 0.3 |
Tsawg dua lossis sib npaug rau 0.4 |
Tsawg dua lossis sib npaug rau 0.5 |
|
Rov Los Los |
Ntau tshaj los yog sib npaug rau 50 |
|
|
|
|
|
|
|
Kev taw qhia |
Ntau dua lossis sib npaug li 55 |
||||||
|
Kev khiav hauj lwm Temp Range |
-45 ~ 85 degree |
||||||
|
Ceeb Toom: Cov Parameter saum toj no yog rau Splitter nrog Connector. Yog tias W/O Connector, Insertion Poob yuav txo los ntawm 0.2dB |
|||||||
Khoom nta
- Tsawg insertion poob thiab siab uniformity
- Tsawg polarization cuam tshuam
- Redundant kev ntseeg tau
- FTTX daim ntawv thov
- CATV network
- Passive Optical Network (PON)
Cov khoom siv
Cov1X64 PLC Fiber Optic Splitteryog qhov zoo tagnrho rau ntau daim ntawv thov, suav nrog:
- Fiber rau qhov taw tes (FTTX)
- Fiber rau lub tsev (FTTH)
- Passive optical networks (PON)
- Local cheeb tsam network (LAN)
- Cable TV (CATV)
- Cov khoom siv kuaj
Kev Tswj Xyuas Zoo
Ntawm Shenzhen Evolux Fiber Co., Ltd., peb siv cov txheej txheem tswj xyuas kom zoo los xyuas kom meej tias peb cov khoom ua tau raws li cov qauv zoo tshaj plaws thiab kev ua haujlwm zoo. Peb txoj hauv kev zoo rau kev lees paub zoo suav nrog kev saib xyuas zoo ntawm txhua theem ntawm kev tsim khoom, los ntawm kev xaiv cov khoom siv raw mus rau qhov kawg ntawm cov khoom kuaj. Peb ntiav cov cuab yeej ntsuas qib siab thiab cov txheej txheem tshuaj xyuas nruj kom lav kev ntseeg tau thiab ua raws li cov qauv thoob ntiaj teb. Peb pab neeg muaj kev ruaj ntseg zoo tsis tu ncua saib xyuas cov txheej txheem thiab siv kev txhim kho, kom ntseeg tau tias txhua yam khoom xa tuaj cuam tshuam txog peb txoj kev mob siab rau kev ua tau zoo. Qhov kev mloog zoo rau kev nthuav dav no ua rau peb muab cov kev daws teeb meem uas koj tuaj yeem ntseeg tau thiab vam khom rau.
FAQ
Txog Peb
Shenzhen Evolux Fiber Co., Ltd. yog ib lub chaw muab kev pabcuam zoo tshaj plaws ntawm fiber ntau optic kev npaj, nteg tawm nyob rau hauv 2013. Peb tsom rau kev txhim kho thiab unwavering zoo nyob rau hauv lub fiber optics kev lag luam. Yog xav paub ntxiv los yog xav tau ib nqe lus rau peb1X64 PLC Fiber Optic Splitter, ua siab zoo cuag peb hnub no ntawmsales@evoluxfiber.comthiabshanna@evoluxfiber.com. Peb cia siab tias yuav pab koj nrog koj cov kev xav tau ntawm fiber ntau optic.
